Noark 108369 Ex9L-N RCCB 4P 25A Type A 300mA Residual Current Circuit Breaker

Login to See Price
21 pcs
Availability:
24h Bialystok
0 pcs
72h Central
21 pcs
SKU
3451
Noark 108369 Ex9L-N RCCB 4P 25A Type A 300mA Residual Current Circuit Breaker is available to buy in increments of 1

NOARK Residual Current Switch 4P 25A 300mA Type A Ex9L-N 108369

The NOARK Ex9L-N 108369 residual current circuit breaker is a reliable protective device dedicated to domestic and industrial installations. Thanks to its sensitivity to sinusoidal and pulsed (Type A) residual current, the device provides effective protection against electric shock, as well as additional protection in the event of insulation damage.

Key product features

  • Manufacturer: Noark
  • Series: Ex9L-N
  • Rated current: 25 A
  • Differential current: 300 mA
  • Current type: Sinusoidal and pulsed (type A)
  • Number of poles: 4 (3P+N)
  • Rated operating voltage: 400 V AC
  • Rated short-circuit current: 6 kA
  • Rated conditional short-circuit current: 6 kA
  • Degree of protection: IP20
  • Dimensions (W x H x D): 72 x 88 x 79 mm

High performance

The NOARK Ex9L-N 108369 residual current circuit breaker features an instantaneous trip time, meaning that it responds instantly to any abnormalities associated with current flow. A rated current of 25 A and a residual current of 300 mA provide effective protection against electrical shock, regardless of installation conditions.

Safety and reliability

The device provides protection in undemanding applications such as domestic installations where standard circuits are used. The circuit breaker operates selectively against other S or S+A type residual current circuit breakers, providing additional safety for the user. The product has a wide operating temperature range of -25°C to +60°C and an IP20 protection rating, making it ideal for a variety of environments.

Easy installation and testing

The switch can be installed on a TH-35 mm rail and the direction of power supply is arbitrary (from above or below), providing installation flexibility. A test button makes it easy to check the operation of the switch, which should be done regularly to ensure that the device is working properly. The product has a mechanical life of up to 20,000 switching cycles and an electrical life of up to 4,000 cycles.

Technical specifications

  • Rated current: 25 A
  • Differential current: 300 mA
  • Rated conditional short-circuit current: 6 kA
  • Operating voltage: 400 V AC
  • Mechanical life: 20,000 switching cycles
  • Electrical life: 4 000 switching cycles
  • Operating temperature: -25°C to +60°C
  • Degree of protection: IP20
  • Certifications: CE, compliance with IEC/EN 61008-1 standards

The NOARK Ex9L-N 108369 residual current circuit breaker is the perfect solution for any installation, providing protection against electric shock and meeting all electrical safety requirements.

More Information
EAN 8592765083692
Manufacturer Noark Electric
Weight 0.200000
Width In Number Of Modular Spacings 4.00
Width 0.00 cm
Height 0.00 cm
Length/Depth 0.00 cm
